4373.2604 - Leser South Africa Sales

BRAND	Leser
Product	4373.2604
Description	safety valve
Internal code	IMP499650
Weight	1.2
Custom code	84814010
Technical specification	Compact Performance safety valve, type 437 closed spring cap, gas-tight ventilation H4, for vapors, gases and liquids Order code output, line 1: K7TM33K4XH03P2CX00V54V65L49MB8 Order code output, line 2: (H01) E-body material: 1.4104/430 1.4104/430 Inlet by weight: (V54) External thread G 1/2 “according to DIN ISO 228-1 Weight connection outlet: (V65) female thread G 1/2 “according to DIN ISO 228-1 Nominal diameter inlet G 1/2" Nominal diameter outlet G 1/2" Pressure stage inlet PN 250 Pressure stage outlet PN 160 d0 (ASME-DIN) [mm] 10.0 Outflow rate D/G: 0.50 Flow rate F: 0.35 Response pressure: 2.50 Pressure unit: bar-g Response pressure [bar-g] 2.50 Response pressure in psi-g: 36.26 Cold setting pressure [bar-g] 2.50 Cold setting pressure [psi-g] 36.26 Operating temperature: 20 Temperature unit: °C - Celsius Operating temperature [°C] 20.00 Operating temperature in °F: 68 Plate, metallic/Wst.: (L49) made of material: 1.4122 Spring material (X00) standard material Colorway: (P2C) 2-layer coating system in RAL 5005 according to LID 1608.02 Acceptances: (M33) Verification of the set pressure test (TRB 513 4.2, TRD 504 3.3.4): EN 10204-3.2 (TÜV-North) Material quality certificate for: (H01) Enclosures — position 1 with material quality certificate 3.1 according to DIN EN 10204 Documentation: (H03) READER CGA Certificate for Global Application acceptance test certificate 3.1 according to DIN EN 10204

Please Contact Us to Order to offer competitive prices and delivery time for Leser - 4373.2604 safety valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in South Africa Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
