5262.1444 Type 526 30 bar Leser Sales In South Africa

BRAND Leser
Product 5262.1444 Type 526 30 bar
Description API Series safety valve
Internal code IMP4803027
Weight 41.6
Custom code 84814010
Technical specification Orifice H, closed spring hood, gas-tight ventilation H4, for vapors, gases and liquids incorporates J69 blocking screw J22 O-ring plate Technical specification: Order Code Output, Line 1: K7RK2SK2RM33J69MB1K4XH03K3FP2A Order Code Output, Line 2: J99X00L39H89H79H65H22L8JK1EL44 Order Code Output, Line 3: J22H01 Case material: (H22) Housing made of material 1.0619 (GP240GH) (with triple certification: WCB, WCC, 1.0619) NPS 2" Nominal Size Entry NPS 3" Nominal Size Outlet d0 (ASME-DIN) [mm] 28.3 Outflow rate D/G: 0.80 Outflow rate F: 0.58 Inlet flange pressure level (H65) 300 lbs according to ASME B 16.5 Outlet flange pressure level (H79) 150 lbs according to ASME B 16.5 Flange sealing surface inlet: (H89) Serrated spiral finish (Ra = 3.2 - 6.3 μm) according to ASME B16.5 Outlet flange sealing surface: (L39) Serrated spiral finish (Ra = 3.2 - 6.3 μm) according to ASME B16.5 Response pressure: 30.00 Pressure unit: bar-g Response pressure [bar-g] 30.00 Response pressure in psi-g: 435.11 Cold setting pressure [bar-g] 30.00 Cold setting pressure [psi-g] 435.11 Operating temperature: 20 Temperature unit: °C - Celsius Operating temperature [°C] 20.00 Operating temperature in °F: 68 Seat bushing material (K1E) Seat bushing material: 1.4408/ASME SA-351 CF8M Metallic plate/Wst.: (L44) made of material 1.4404/316L Soft sealing plate: (J22) Ventilation/cap: (J69) H4 with locking screw (test gag) Guide wheel material: (K3F) Guide disc material: 1.0501 Spindle material (K4X) Spindle material:1.4021 Adjusting ring material: (K2S) Locking screw material: (K2R) Spring hood material: (J99) Spring hood material 1.0619/ WCB/ WCC spring material (X00) standard material Wst. stud screws Item 55 (L8J) Material of stud screws Pos. 55:1.7225/ SA-193 B7/ SA-320 L7 Wst. hexagon nuts Item 56 (L9J) Material of hexagon nuts Pos. 56:1.7225/SA-194 size 7/SA-320 7L Colouring: (P2A) 1-layer coating system in RAL 5005 in accordance with LID 1608.03 Approvals: (M33) Proof of adjustment pressure test (TRB 513 4.2, TRD 504 3.3.4): EN 10204-3.2 (TÜV North) Material quality certificate for: (H01) Housing — position 1 with material quality certificate 3.1 in accordance with DIN EN 10204 Documentation: (H03) LESER CGA Certificate for Global Application Acceptance Test Certificate 3.1 according to DIN EN 10204 Day no., valve 1: PSV - 71970 Type and location of tag no.: (M25) Labelling with tag (foil/ paper) Design in accordance with serial no. 10085593

         Temui kualiti dan prestasi unggulLeser 5262.1444 Type 526 30 bar denganImpexron GMBH dalamSouth Africa . Sama ada anda mencari kebolehpercayaan atau kecekapan, produk ini memenuhi semua keperluan industri anda.

The5262.1444 Type 526 30 bar direka untuk memberikan prestasi optimum dan ketahanan dalam pelbagai aplikasi. Dikenali dengan pembinaan berkualiti tinggi dan ciri-ciri inovatif, ia adalah pilihan utama untuk profesional.

Ciri-ciri Utama5262.1444 Type 526 30 bar :

  • Prestasi Tinggi: Direka untuk memberikan hasil yang luar biasa.
  • Pembinaan Tahan Lama: Dibina dengan bahan berkualiti tinggi untuk kegunaan tahan lama.
  • Reka Bentuk Inovatif: Menggabungkan teknologi terkini untuk kecekapan yang dipertingkatkan.
  • Kos-Efektif: Menawarkan nilai terbaik untuk wang dengan harga yang kompetitif.

PadaImpexron GMBH , kami menawarkan5262.1444 Type 526 30 bar pada harga yang kompetitif dan dengan masa penghantaran terpantas di seluruhSouth Africa . Pasukan pakar kami bersedia untuk membantu anda dengan semua pertanyaan anda dan menyediakan penyelesaian yang disesuaikan untuk memenuhi keperluan khusus anda.

Mengapa MemilihImpexron GMBH ?

  • Bantuan Pakar: Dapatkan bantuan daripada pasukan kami yang berpengetahuan untuk semua soalan berkaitan produk anda.
  • Harga Kompetitif: Kami menawarkan beberapa harga terbaik di pasaran.
  • Penghantaran Cepat: Manfaat daripada rangkaian penghantaran kami yang cekap untuk masa pemulihan yang cepat.
  • Kepuasan Pelanggan: Komitmen kami terhadap perkhidmatan pelanggan memastikan pengalaman membeli yang hebat.

Dapatkan Sebut Harga Anda Hari Ini! Bersedia untuk meningkatkan operasi anda dengan5262.1444 Type 526 30 bar ? Hubungi kami sekarang untuk sebut harga yang diperibadikan. Isi borang di bawah atau hantarkan e-mel kepada kami dengan pertanyaan anda. Biar kami membantu anda membuat pilihan yang menjimatkan kos dan dipacu kualiti untuk perniagaan anda.

Notis Penting: Semasa kami membekalkanLeser produk,Impexron GMBH bukan pengedar sah . Semua hak adalah terpelihara oleh pengilang dan rakan kongsi rasmi mereka.

Where can I buy :product by :brand in the South Africa?

You can purchase :product by :brand from Impexron GMBH.We serve customers across the South Africa, offering competitive prices and reliable service.

What is the price of :product?

For customised pricing and availability, please fill out our or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of :brand in the South Africa?

While we are not the official distributor or seller of :brand in the South Africa, we source our products from reliable channels and offer you original :brand equipment at competitive prices.

How can I access :product catalogues, user manuals, technical documents, and PDFs?

You can access catalogues, user manuals, and technical documents for :product on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for :product?

We can assist you in contacting the manufacturer to ensure you receive the support you need.
