5264.0142 - Leser South Africa Sales

BRAND	Leser
Product	5264.0142
Description	API Series safety valve
Internal code	IMP3372817
Weight	3
Technical specification	Type 526, Orifice D, closed spring hood, gas-tight cap H2, for vapors, gases and liquids Technical specification: Order code output, line 1: K7SK2SK2RMB1K4ZH03I63J54X00L39 Order code output, line 2: H89H80H70H28L8KK1FL44H01N68 Medium: gases gasses Case material: (H28) 1.4408/CF8M NPS 1 1/2" diameter inlet Nominal diameter outlet NPS 3" d0 (ASMEDIN) [mm] 14.0 Outflow coefficient D/G: 0.45 Outflow coefficient F: 0.32 Flange pressure stage entry (H70) 2500 lbs according to ASME B 16.5 Flange pressure stage outlet (H80) 300 lbs according to ASME B 16.5 Inlet flange sealing surface: (H89) serrated spiral finish (Ra = 3.2 - 6.3 μm) according to ASME B16.5 Outlet flange sealing surface: (L39) serrated spiral finish (Ra = 3.2 - 6.3 μm) according to ASME B16.5 Response pressure: 344.80 Pressure unit: bar-g Response pressure [bar-g] 344.80 Response pressure in psi-g: 5,000.90 Cold setting pressure [bar-g] 344.80 Cold setting pressure [psi-g] 5,000.90 Operating temperature: 20 Temperature unit: °C - Celsius Operating temperature [°C] 20.00 Operating temperature in °F: 68 Seat bushing material (K1F) Seat bush material: 1.4408/ASME SA-351 CF8M stellized plate, metallic/Wst.: (L44) Made from 1.4404/316L Guide wheel material: (I63) Guide wheel material: 1.4404/316L Spindle material (K4Z) Spindle material: 1.4404/316L Adjusting ring material: (K2S) Locking screw material: (K2R) Hood material: (J54) Spring hood material 1.4408/CF8M, cast version Spring material (X00) standard material Wst stud screws Item 55 (L8K) Material stud screws pos. 55:1.4401/A4-70/SA-193+320 B8M Wst hexagon nuts Item 56 (L9K) Material hexagon nuts Pos. 56:1.4401/A4-70/SA-194-8M Material quality certificate for: (H01) Housing — position 1 with material quality certificate 3.1 in accordance with DIN EN 10204 Delivery specification: (N68) Approval in accordance with ASME Sec. XIII for ASME VIII DIV. 1 (UV stamp) Documentation: (H03) LESER CGA Certificate for Global Application Inspection Certificate 3.1 in accordance with DIN EN 10204

Please Contact Us to Order to offer competitive prices and delivery time for Leser - 5264.0142 API Series safety valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in South Africa Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
