BRAND | Merkle |
Product | BZ 320.25/16.03.201.130.NR33.V |
Description | Cylinder |
Internal code | IMP5035173 |
Custom code | 84122180 |
Technical specification | Article 311795 AHP BLOCK CYLINDER BZ 320.25/16.03.201.130 NR33.V Weight 4 kg Customs tariff no./ origin 84122180/DE Block cylinder type Cylinder type BZ 320 designation Piston diameter 25 mm Bar diameter 16mm Design 03 = mounting holes on the sides, connection: pipe thread Function type 201 = double-acting Hub 130 mm Viton sealing type - up to max. 180°C max. operating pressure 320 bar Groove/Fastening NR = Right Groove h2: position of the groove 33 mm BZ 320: Stroke > 100 mm Please note the total length! |
Discover the superior quality and performance of the Merkle BZ 320.25/16.03.201.130.NR33.V with Impexron GMBH in South Africa . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BZ 320.25/16.03.201.130.NR33.V is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BZ 320.25/16.03.201.130.NR33.V :
At Impexron GMBH , we offer the BZ 320.25/16.03.201.130.NR33.V at competitive prices and with the fastest delivery times across South Africa . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the BZ 320.25/16.03.201.130.NR33.V ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Merkle products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
