BRAND | Merkle |
Product | 131773 |
Description | HYDRAULIC CYLINDER |
Internal code | IMP5026387 |
Custom code | 84122180 |
Technical specification | Article 131773 AHP BLOCK CYLINDER BZ 500.125/80.02.201.100 H/60 Weight 56.4 kg Customs tariff no./ origin 84122180/DE Block cylinder type cylinder type designation BZ 500 Piston diameter 125 mm Bar diameter 80 mm Design 02 = 4 mounting holes, lowered at the rear, connection: pipe thread Function type 201 = double-acting Stroke 100 mm Stroke reduction to 60mm max. operating pressure 500 bar |
Discover the superior quality and performance of the Merkle 131773 with Impexron GMBH in South Africa . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 131773 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 131773 :
At Impexron GMBH , we offer the 131773 at competitive prices and with the fastest delivery times across South Africa . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 131773 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Merkle products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
