| BRAND | Ifm |
| Product | II5944 |
| Description | Inductive sensor. |
| Internal code | IMP1119733 |
| Weight | 1 |
| Custom code | 85365019 |
| Technical specification | Induktiver Sensor; M30 x 1,5 / L = 58 mm; Schaltabst Product characteristics Electrical design PNP Output function normally open Sensing range [mm] 12 Housing threaded type Dimensions [mm] M30 x 1.5 / L = 58 Application Special feature Increased sensing range Electrical data Operating voltage [V] 10...36 DC Current consumption [mA] < 15 Protection class II Reverse polarity protection yes Outputs Electrical design PNP Output function normally open Max. voltage drop switching output DC [V] 2.5 Permanent current rating of switching output DC [mA] 250 Switching frequency DC [Hz] 100 Short-circuit protection yes Type of short-circuit protection pulsed Overload protection yes Detection zone Sensing range [mm] 12 Operating distance [mm] 0...9.72 Increased sensing range yes Accuracy / deviations Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3 Hysteresis [% of Sr] 1...20 Operating conditions Ambient temperature [°C] -40...70 Protection IP 69K; (cable plugs: IP 68) |
Please Contact Us to Order to offer competitive prices and delivery time for Ifm - II5944 Inductive sensor. number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in South Africa Industrial products Market.
