BRAND | Vivoil Oleodinamica Vivolo |
Product | P/N: 023-011-01750, Type: X2T5541HSRD |
Description | Front section external gear pump size 2 with aluminum body and aluminum flanges |
Internal code | IMP4460529 |
Custom code | 84136031 |
Technical specification | DXV2T/22S-Ø80-SCF.03-40/35-DS 22.8 ccm/U - left turning - 200 bar Delivery volume: 22.8 ccm/u Direction of rotation: left-handed Mounting flange: fitting diameter 80 mm - 4 hole attachment 100 mm x 72 mm Mounting flange for middle or end section size 2: fitting diameter 36.5 mm - 4 hole fastening 60 mm x 60 mm (mounting holes Ø 11 mm) Drive shaft: toothed 9 teeth DIN5482 - 17 x 14 - diameter 16.5 h11 - through drive toothed 9 teeth DIN5482 - 17 x 14 - diameter 16.5 h11 Suction connection: LK 40 mm BOSCH - M6 x 1 Pressure connection: LK 35 mm BOSCH - M6 x 1 Installation length: 114.4 mm Sealing material: NBR Permissible shaft torque: 86.2 Nm continuous pressure limited by drive shaft: 200 bar Continuous pressure: 200 bar Peak pressure (max 0.5 sec.): 240 bar Minimum speed: 700 rpm Maximum speed: 3000 rpm” |
Please Contact Us to Order to offer competitive prices and delivery time for Vivoil Oleodinamica Vivolo - P/N: 023-011-01750, Type: X2T5541HSRD Front section external gear pump size 2 with aluminum body and aluminum flanges number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in South Africa Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
